A 12 m bundle of I-beam doesn’t care how pretty your warehouse looks; it cares about gravity, aisle width, and the first person who tries to pull it free without unstacking six tons of neighbours. Herochu’s roll-out cantilever family—HC-G and HC-B lines—lets one operator glide out a single 6 t beam in under thirty seconds while the forklift waits, engine idling, aisle clear. No secondary handling, no leaning tower of steel, no overtime ticket.

Category Heavy Duty Cantilever Racking System Tag Cantilever Racks & Heavy-Duty Shelf Systems for Warehouses

Herochu Cantilever Racks & Heavy-Duty Shelf Systems
Dense storage for long steel, pipe, sheet — CE / UE / ISO 9001 — from $3,099 ex-works

Why roll-out beats static every time

Traditional cantilever arms are cheap until you count the hidden invoice: the half-hour spent shuffling bundles to reach the middle, the scratched paint that becomes a rust claim, the safety inspector who red-tags your aisle for overhang. Roll-out trays turn the arm into a moving table. Precision-rolled bearings sit inside sealed cams, rated 1.3 t each and tested to 30,000 cycles with mill-scale dust. Pull force stays under 25 kg for a 6 t load, so the crane can stay parked—saving 2 min per pick, 200 picks per week, 133 labour hours per year. At $40 per hour that’s $5,320 the rack pays you before you talk about floor space.

From 3 m to 12 m without a weld on site

The HC-G series handles long material: angle, channel, RHS, drill pipe. HC-G6053S gives you three extendable arms plus a fixed top tier, 2 t per arm, total rack capacity 8 t, footprint only 3.5 m long. Need more muscle? HC-G9055D doubles the arms, pushes capacity to 35 t, yet the aisle width stays 800 mm—exactly the depth of one tray. If your stock grows, bolt-on bays splice together with fish-plates and four M16 bolts; no hot work, no shutdown. Uprights are laser-cut from 8 mm S355 on a 3 kW fibre line, tolerance ±0.1 mm, so every arm seats like a calibre round. Zinc-nickel flake finish passes 1,000 h salt spray, triple the life of cheap powder coat.

Sheet-metal heaven: HC-B line with sealed drawers

For plate and sheet the HC-B family borrows the same roll-out DNA but adds replaceable polymer glides so aluminium doesn’t gall and stainless doesn’t pick up iron transfer. HC-B6020-66 stores 6 m × 2 m plates up to 6 t per drawer, five active levels plus a weather-sealed top for remnants. Drawer pitch adjusts on 50 mm centres—today 20 mm mild-steel, tomorrow 5 mm tread plate with rubber dividers. Optional RFID antenna laminated in the side plate logs heat number and remnant size the moment the crane lifts, pushing data to your MES without a handheld scanner.

Aisle width = tray depth: reclaim 40 % floor area

Static racks need 3–4 m clear aisle so forks can angle in. Roll-out trays demand only their own depth—800 mm for HC-G9055D—because the load comes to the forklift. In a 40 × 25 m bay that single change frees 400 m², enough for two extra laser cutters or twelve more pallet locations. Roof height is no longer a penalty: bays bolt together vertically, so you can start at 3 m and grow to 8 m when the new building lease is signed.

Safety that satisfies insurers, not just auditors

Anti-sway spine: 6 mm diaphragm laser-welded between uprights eliminates lateral whip under overhead crane acceleration.
Double-pawl safety: forged pin rated 5 t shear, visible safety-red, removable only when tray is empty and tilted.
Photoelectric presence bar: optional across tray mouth; if boots break the beam the DC assist motor reverses 100 mm—no PLC programming required.
Earth bonding: 16 mm copper busbar factory-welded to every frame; stainless and aluminium stay free of stray-current pitting.
Seismic upgrade: cross-braces and base plates engineered for 0.48 g zones—California, British Columbia, New Zealand, we ship with the PE stamp.

PLC or muscle: you choose the power

Manual pull-out is standard on HC-G6053S—perfect for low-cycle workshops where the overhead crane is busy elsewhere. Step up to PLC frequency-conversion control and you get soft-start, soft-stop, torque sensing, and HMI that speaks English, Spanish, or Mandarin. Encoder feedback means the tray stops within ±2 mm so the vacuum lifter aligns first time, every time. Motor is 24 V DC for safety, battery-backup hand-held pendant for power cuts, and consumption is 0.1 kWh per full extension—less than the coffee machine.

ROI you can defend in a finance meeting

Assume 250 t of long material in inventory at $700 per ton, 2 % scrap from double-handling, and eight picks per day saving 3 min each at $50 crane hour:

Scrap reduction: 250 t × $700 × 2 % = $3,500
Labour saving: 8 × 3 min × 250 days × $50/60 = $5,000
Floor space value: 400 m² × $90/m²/year = $36,000 (opportunity cost)

Total first-year benefit: $44,500
HC-G9055D double-sided system: $8,799
Payback: 2.4 months—before you count faster laser change-overs, reduced overtime, and the marketing value of a “world-class” material store.

Sustainability that fits the ESG slide

Steel content is 97 % recycled; the real win is damage avoidance. Every ton of beam that skips the scrap bin saves 1.85 t CO₂ versus remelt. Prevent 10 t of scrap per year and you erase the emissions of four passenger cars—without a single solar panel on the roof.

Colour, capacity, control—customise in three clicks

Orange/blue is standard because safety studies show the contrast cuts forklift incidents by 12 %. Prefer corporate grey with yellow stripes? No MOQ, no up-charge. Arms, trays, pitch, load, motor, and colour are all configurable in the same BOM. We laser-cut, pre-assemble, and photograph every bay under LED light so you know the fit before it leaves the factory.

Shipping & pricing—no bait, no switch

$3,099 buys HC-G6053S single-sided starter: three roll-out arms plus fixed top, 2 t per arm, 8 t total, FOB Shanghai. Add $229 per extra arm, $449 per bolt-on bay. Full 12 m double-sided monster (HC-G12055D) lands around $11,700—still less than the invoice for one rejected oil-and-gas pipeline bundle. LCL or 40 ft HQ quotes in 12 h; payment by LC, Net 30, or Shopify Pay—your call.

Next step—see it glide

Scan the QR code on herochu.com and watch a 47-second clip: one operator pulls a 9 m beam, loads onto a waiting truck, and scans the barcode—total elapsed 32 s. Then book a 15-min Teams slot; we’ll drop a 3-D STEP model of your exact aisle into your inbox while we’re still talking.

Stop treating long steel like a juggling act and start banking the margin hidden in your aisle width. Herochu roll-out cantilever racks: bring the load to you, protect the metal, protect the profit, from $3,099 today.
